1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel

Ask Lasest Price
Brand Name :	Shine Abrasives
Model Number :	Resin Bond Diamond Wheels
Certification :	ISO
Price :	FOB
Payment Terms :	L/C, T/T
Supply Ability :	10000 pcs in one week
Delivery Time :	5 working days

Add to Cart

Product Details
Company Profile

1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel

2023 1A1 Style Flat Resin Bond Diamond Grinding Wheel For Tungsten Steel.

The flat resin diamond grinding wheel is mainly used for cylindrical grinding and cutting edge processing of cemented carbide.

Resin bond diamond grinding wheel is suitable for grinding metal
and non-metal hard and brittle materials with low iron content,such
as cemented carbide,high alumina porcelain, optical glass, agate
gemstone, semiconductor material, ceramics, stone, etc.

Product Description:
Resin Bond Diamond Grinding Wheel is the most common choice in
Diamond and CBN super-abrasive wheels. It forms a bond structure
that keep the wheel sharp cutting, super surface finish, efficient
grinding and less heat generating. The most important is that it is
very cost effective. It is more competitive than Vitrified bond and
Metal Bond. So it is broadly applied in the grinding industries.
Type1A1 Flat resin bond diamond grinding wheel
Concentration50%, 75% 100% 125% 150%
Mesh46#, 60#, 80#, 100#, 120# (coarse grinding);
120#, 150#, 180#, 200#, 240# (medium grinding);
280#, 320#, 400#, 500#, 600# (fine grinding);
800#, 1000#, 1200#, 1500#, 2000#, 3000# (polishing)
MaterialSynthetic Diamond / CBN Powder
Specification
( Specification sizes can be customized )D75-H10-T5-X10 / D150-H19-X5-T5 / D125-T10-X10- H20/31.75 /
D100-T10-X10- H20/31.75
D175-H127-X4-T5 / D250-H40-X10-T3 / D300-H127-X10-T40 /
D350-H127-T20-X10 / D400-H127-T40-X10 / D500-H203-X10-T32
ApplicationHard alloy, high alumina porcelain, optical glass, agate gemstone,
semiconductor material, ceramics, stone, etc.

Features of Resin Bond Diamond Grinding Wheel
1. High grinding efficiency, relative low consumption while
grinding;
2. Good self sharpness, small thermal power and seldom clogging,
which can greatly reduce the incidence of burn while grinding;
3. With certain elasticity, it is good for improving the surface
roughness of workpiece, which is mainly used for fine grinding,
semi fine grinding, knife grinding, polishing and other processing;
4. Low temperature curing, short production cycle, relative simple
equipment & supplying process; Also, since the resin has fluidity,
it is easy to shaped as the wheel with complex surface.
